V-Series V1-V15

V-Series V1-V15

The Flow Monitor in V-series V1-V15 is a very robust and reliable Flow Monitor which is insensitive to magnetic fields. It has a micro-switch, which is adjustable within the measuring range and can be set to alarm at high or low flow, to protect equipment such as cooling water and lubricating oil circuits.

Micro switch:

one adjustable SPDT micro switches, repeatability <2%

Switch rating:

max 15 A @ 480 VAC & 2 A @ 30 VDC

Pipe section:

brass, powder coated steel, stainless steel (other material on request)

Pipe sizes:

DN 15 - DN 550

Housing:

aluminum, stainless steel

Measuring range:

1:2 or 1:5 turndown

IP class:

IP65 as standard

Temperature spec:

dependent on configuration. Contact Eletta

Options:

Atex certified, Indication display, LED indicator as an option High temperature, separate mounting, parallell mounting with M - Series
